| Model | CS-HB8-R200-1M8WFL |
|---|---|
| Camera | |
| Image Sensor | 1/2.8'' 8-Megapixel Progressive Scan CMOS Sensor |
| Minimum Illumination | 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR |
| Shutter Speed | Self-adaptive shutter |
| Lens | 4mm@ F1.2 Diagonal angle: 104° Horizontal angle: 83° Vertical angle:44° |
| PT Angle | Pan: 340°, Tilt: 75° |
| Day & Night | IR-cut filter with auto switch |
| DNR | 3D DNR |
| Night Vision | 15 m |
| Video & Audio | |
| Max Resolution | 4K (3840 × 2160） |
| Frame Rate | Max. 15fps; Self-adaptive during network transmission |
| Video Compression | H.265 / H.264 |
| Video Bit Rate | Ultra-HD; Quad HD; Full HD; Hi-Def; Adaptive bit rate |
| Audio Bit Rate | Self-adaptive |
| Max. Bitrate | 4 Mbps |
| Network | |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n, 802.11ax |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20 MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 72Mbps, 11ax: 114Mbps |
| Wi-Fi Pairing | AP pairing |
| Protocol | EZVIZ Cloud Proprietary Protocol |
| Interface Protocol | EZVIZ Cloud Proprietary Protocol |
| Minimum Network Requirement | 8 Mbps |
| Function | |
| Smart Alarm | AI-powered human shape detection AI-powered vehicle shape detection |
| Two-Way Talk | Supports |
| General Function | Anti-Flicker, Heart Beat, Password Protection, Watermark |
| Storage | |
| Local Storage | Supports microSD card (max. 512 GB) |
| Cloud Storage | Supports EZVIZ CloudPlay storage (Subscription required) |
| General | |
| Operating Conditions | -20 °C to 50 °C (-4 °F to 122 °F), Humidity 95% or less (non-condensing) |
| IP Grade | IP65 |
| Power Supply | DC 5 V / 2 A (Adapter needs to be purchased separately) |
| Battery Capacity | 10,400 mAh |
| Power Consumption | Max.10 W |
| Product Dimensions | 184 × 102 × 168 mm (7.24 × 4.02 × 6.61 inch ) |
| Packaging Dimensions | 205 × 145 × 194 mm (8.07 × 5.70 × 7.64 inch) |
| Product Weight | 780 g (21.51 oz) |
| Weight with Package | 1312 g (46.61 oz) |
| In the box | |
| In the box | - HB8 Pro Camera |
| - Drilling Template | |
| - Type-C Cable | |
| - Screw Kit | |
| - Quick Installation Guide | |
| - Regulatory Information × 3 | |
| - Quick Start Guide | |
| Certifications | |
| Certifications | CE / REACH / WEEE / RoHS |
| ITM No. | ITM006064 |
|---|---|
| Manufacturer | EZVIZ |
| Type of Product | simple |
| New Product | Yes |
